Image Sensor

1/2.9" SONY Low Illumination CMOS Sensor

Resolution

2MP 1080P

Effective Pixels

1985(H)*1105(V)

Compression

H.264/H.264+/H.265/H.265+/JPEG/AVI /MJPEG

TV System

PAL/NTSC

Electronic Shutter Time

Auto: PAL 1/25-1/10000Sec; NTSC 1/25-1/10000Sec

S/N Ratio

≥52dB

Scanning System

Progressive

Video Output

Network

Reset Button

Optional

Lens

Focus Length

3.6mm (2.8mm/6mm Optional)

Focus Control

Fixed

Lens Type

Fixed

Pixels

3MP

Night Vision

Infrared LED

14µ x 18PCS

Infrared Distance

20M

IR Status

Under 10 Lux By CDS

IR Power On

CDS Auto Control

Network

Ethernet

RJ-45 (10/100Base-T)

Protocol

TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP,NTP,SMTP

ONVIF

Support ONVIF 2.4

P2P

YES, Support QR Code

POE

Optional, Support IEEE 802.3af

Video Delay

0.3S (Within the Lan)

Main Stream 1

1920*1080@30fps

Main Stream 2

/

Main Stream 3

/

Sub Stream 1

720*480@30fps

Sub Stream 2

/

Sub Stream 3

/

Tri Stream

352*288@30fps

IE Brower

IE8-11, Google Chrome, Firefox, Safari, Mac Safari

Smart Phone

iPhone, iPad, Android, Android Pad

Camera Features

Day/Night

Color/ B&W (IR-CUT )

Image Config

Saturation/Brightness/Contrast /Sharpness, Mirror, 3D NR , White Balance, FLK(Flicker Control)

Starlight

/

Corridor Pattern

/

Defog Mode

Support

ROI

Support

BLC

Support

HDR

/

WDR

Support

Motion Detection

Support

Privacy Masking

3 Rectangular Zone

Recording Mode

NVR/NAS/CMS/Web

Language

Chinese Simplified, Chinese Traditional, English, Bulgarian, Polish, Farsi, German, Russian, French, Korean, Portuguese, Japanese, Turkish, Spanish, Hebrew, Italian,Nederlands

Interface

Audio

Optional

Alarm

/

SD Card Slot

Optional, Support Max 128GB

RS485

/

General

Housing

Metal , IP66

Anti-cut Bracket

NO

IR Cut Filter

YES

Operation Temperature

-20℃ ~ +60℃ RH95% Max

Storage Temperature

-20℃ ~ +60℃ RH95% Max

Power Source

DC12V±10%, 850mA

Dimension

￠94.5 x 76(H) mm

Weight

450g
